2GHz to 6GHz
Up to 0.5m
- Hand held (dimensions excluding connectors and handles: 240x16x90mm)
- Horn antennas
- Fully screened
- Automatic Mapping Programme available (at no extra cost)
- Controller to unit cable available in longer lengths up to 50m (standard length 6m)
- Compatible with Groundvue 3. For use at higher speeds, use with the Groundvue 3 controller as 1 or more of a maximum 4 channels.
Direct to solid disk
Extremely high (5mm)
- A long term data storage system is essential
- A basic 12V battery charger is required
- A waterproof Groundvue datalogger is required for data storage and system control
Additional analytical software – the ReflexW package – is also available. Details on request.
